Element type rear window antenna

Towing prep pkg -inc: 3500# towing capacity, reprogrammed ECU, heavy duty transmission cooler & radiator fan *Requires TTH Towing Receiver Hitch to complete towing pkg*

18\" x 7.5\" aluminum wheels

Rear privacy glass

Body-color pwr heated mirrors

Halogen headlights w/auto off

Body-color front/rear bumper

Body-color roof spoiler

T155/90R18 temporary spare

P245/60R18 all-season tires

Body-color door handles

Variable intermittent rear wiper w/washer

Variable intermittent windshield wipers

Crushable brake pedal assembly

2nd row child seat lower anchors & tethers (LATCH system)

Front belts w/pretensioners & force limiters

Child safety rear door locks

Front seat active headrests

3-point seat belts for all seating positions

Front/2nd row/3rd row side impact air curtains w/rollover protection

Front side airbags

Driver & front passenger airbags -inc: passenger weight sensor

Side-impact door beams

Front/rear crumple zones

Roll stability control

Dynamic stability control

Traction control

Electronic brakeforce distribution

4-wheel anti-lock brakes

Rear under floor storage

(2) rear coat hooks

(3) passenger assist grips

Driver side footrest

Leather-wrapped shift knob

Overhead console w/sunglass storage

Piano black interior trim

Front driver-side seatback map pocket

Dual sun visors w/illuminated vanity mirrors, extenders, cloth covers

Lighting-inc: front door/cargo courtesy lamps, ignition, map lamps, glove box

Illuminated entry

Front/rear door storage pockets w/bottle holders

(3) auxiliary 12-volt pwr outlets

Remote fuel door

Glove box w/lock

Rear window defogger w/timer

Rear heater ducts

3-zone automatic climate control

Cruise control

Pwr windows w/driver & passenger one-touch up/down & anti-pinch

Tire pressure monitoring system

Instrumentation-inc: tachometer, (2) trip odometers, trip computer, coolant temp/fuel gauges, outside temp display, digital clock

Leather-wrapped tilt/telescopic steering wheel w/mounted audio controls

Full floor carpeting

(4) 3rd row cup holders

2nd row center armrest w/(2) cup holders

Front leather-wrapped center console armrest w/storage

Front center console w/(2) cup holders

All position adjustable headrests

3rd row seating

60/40 split fold-flat 2nd row reclining seats w/tilt & slide rear-access mechanism

Heated front reclining bucket seats w/8-way pwr adjustable driver seat, 4-way pwr adjustable passenger seat, pwr driver lumbar support, high/low adjustable heating

STANDARD PAINT -PT:

PREMIUM PAINT JCP:

NATIONAL DESTINATION CHARGE ADJUSTMENT -NAT:

ALASKA DESTINATION CHARGE ADJUSTMENT -inc: additional destination charge for Alaska -ALHI:

BLACK, LEATHER SEAT TRIM TB4:

SAND, LEATHER SEAT TRIM TB5:

MOONROOF & BOSE AUDIO PKG -inc: pwr glass sliding moonroof w/interior sunshade, Bose Centerpoint 5.1 surround sound system w/(10) speakers, SIRIUS satellite radio w/(4) month subscription (REQ: 1CD 6-Disc CD Changer) (REQ: 1LG Pwr Liftgate Pkg) 1MC:

TOURING PWR LIFTGATE PKG -inc: Mazda advanced keyless entry system & start system, pwr open/close rear hatch (REQ: 1MC Moonroof & Bose Audio Pkg) 1LG:

6-DISC CD/MP3 CHANGER W/MULTI-INFORMATION DISPLAY -inc: 4.3" color LCD display, rearview camera, Bluetooth audio profile, bright finish liftgate garnish (REQ: 1MC Moonroof & Bose Audio Pkg) 1CD:

COPPER RED MICA 32V:

LIQUID SILVER METALLIC 38P:

DOLPHIN GRAY MICA 39T:

STORMY BLUE MICA 35J:

BRILLIANT BLACK A3F:

CRYSTAL WHITE PEARL MICA 34K:

BURGLAR ALARM -inc: shock sensor (N/A w/RSE Remote Engine Start) (PIO) 1PS:

BACK UP CAMERA W/AUTO-DIMMING MIRROR DISPLAY (N/A w/1MC Moonroof & Bose Audio Pkg) (PIO) 1RV:

CARPETED & COLOR KEYED CARGO MAT (PIO) CGM:

ALL WEATHER FLOOR MATS (PIO) FLA:

CARGO NET (PIO) CGN:

MOONROOF WIND DEFLECTOR (REQ: 1MC Moonroof & Bose Audio Pkg) (PIO) MND:

AUTO-DIMMING MIRROR -inc: compass, HomeLink (PIO) MRH:

STAINLESS STEEL REAR BUMPER GUARD (PIO) RBS:

RETRACTABLE CARGO COVER (N/A w/1LG Pwr Liftgate Pkg) (PIO) RCC:

ROOF RAILS (PIO) RCK:

REMOTE ENGINE START (N/A w/1PS Burglar Alarm) (PIO) RSE:

SIRIUS SATELLITE RADIO -inc: (4) month subscription *N/A in AK or HI* *Dealer installed switch box req to maintain Bluetooth or aux input jack function w/installation of SIRIUS satellite radio* (PIO) SAT:

FRONT/REAR SPLASH GUARDS (PIO) SGB:

TRAILER CLASS II HITCH RECEIVER -inc: hitch cover, wiring harness (PIO) TTH:

WHEEL LOCKS (PIO) WLK:

NewCondition:

9086Stock:

2012Year:

MazdaManufacturer:

CX-9Model:

AWD TouringTrim:

Dolphin Gray MicaExterior Color:

BlackInterior Color:

0Mileage:

Active torque split all-wheel driveDrivetrain:

3.7l Dohc 24-valve V6Engine:

6-speed A/tTransmission:

3.7L/227Displacement:

273 SAE Net Horsepower @ RPM:

270 SAE Net Torque @ RPM:

16City MPG:

22Hwy MPG:

4546Base Curb Weight (lbs):

4WD Sport Utility VehiclesEPA Classification:

14.1Total Cooling System Capacity (qts):

20.1Fuel Tank Capacity, Approx (gal):

3EPA Greenhouse Gas Score:

9.6Tons/yr of CO2 Emissions @ 15K mi/year:

- TBD -Cold Cranking Amps @ 0° F (Primary):

110Maximum Alternator Capacity (amps):

Mazda CX-9Vehicle Name:

4 Door Sport Utility VehicleBody Style:

19Fuel Economy Est-Combined (N/A):

16EPA Fuel Economy Est - City (MPG):

22EPA Fuel Economy Est - Hwy (MPG):

3500Dead Weight Hitch - Max Trailer Wt. (lbs):

350Dead Weight Hitch - Max Tongue Wt. (lbs):

3500Wt Distributing Hitch - Max Trailer Wt. (lbs):

525Wt Distributing Hitch - Max Tongue Wt. (lbs):

Pwr Rack & PinionSteering Type:

16.3Steering Ratio (:1), Overall:

3.1Lock to Lock Turns (Steering):

37.4Turning Diameter - Curb to Curb (ft):

N/ATurning Diameter - Wall to Wall (ft):

3.7l Dohc 24-valve V6Engine Type:

3.7L/227Displacement:

Electronic Fuel InjectinoFuel System:

273 @ 6250SAE Net Horsepower @ RPM:

270 @ 4250SAE Net Torque @ RPM:

IndependentSuspension Type - Front:

Multi-LinkSuspension Type - Rear:

- TBD -Shock Absorber Diameter - Front (mm):

- TBD -Shock Absorber Diameter - Rear (mm):

- TBD -Stabilizer Bar Diameter - Front (in):

- TBD -Stabilizer Bar Diameter - Rear (in):

N/AFront Tire Order Code:

N/ARear Tire Order Code:

N/ASpare Tire Order Code:

P245/60R18Front Tire Size:

P245/60R18Rear Tire Size:

T155/90R18Spare Tire Size:

18 x 7.5Front Wheel Size (in):

18 x 7.5Rear Wheel Size (in):

CompactSpare Wheel Size (in):

AluminumFront Wheel Material:

AluminumRear Wheel Material:

- TBD -Spare Wheel Material:

PwrBrake Type:

4-wheelBrake ABS System:

YesDisc - Front (Yes or ):

YesDisc - Rear (Yes or ):

12.6 x - TBD -Front Brake Rotor Diam x Thickness (in):

12.8 x - TBD -Rear Brake Rotor Diam x Thickness (in):

- TBD -Cargo Area Length @ Floor to Seat 1 (in):

48.9Cargo Area Length @ Floor to Seat 2 (in):

19.0Cargo Area Length @ Floor to Seat 3 (in):

58.5Cargo Area Width @ Beltline (in):

46.1Cargo Box Width @ Wheelhousings (in):

34.8Cargo Box (Area) Height (in):

100.7Cargo Volume to Seat 1 (ft³):

48.3Cargo Volume to Seat 2 (ft³):

17.2Cargo Volume to Seat 3 (ft³):

113.2Wheelbase (in):

200.2Length, Overall (in):

76.2Width, Max w/o mirrors (in):

68.0Height, Overall (in):

65.1Track Width, Front (in):

64.7Track Width, Rear (in):

8.0Min Ground Clearance (in):

31.7Rear Door Opening Height (in):

47.3Rear Door Opening Width (in):

31.3Liftover Height (in):

Active torque split all-wheel driveDrivetrain:

6Trans Type:

6-speed A/tTrans Description Cont.:

4.14First Gear Ratio (:1):

2.37Second Gear Ratio (:1):

1.55Third Gear Ratio (:1):

1.15Fourth Gear Ratio (:1):

0.85Fifth Gear Ratio (:1):

0.68Sixth Gear Ratio (:1):

3.39Reverse Ratio (:1):

3.46Final Drive Axle Ratio (:1):

7Passenger Capacity:

139.4Passenger Volume (ft³):

39.6Front Head Room (in):

40.9Front Leg Room (in):

59.4Front Shoulder Room (in):

56.5Front Hip Room (in):

39.0Second Head Room (in):

39.8Second Leg Room (in):

58.7Second Shoulder Room (in):

56.0Second Hip Room (in):

35.4Third Head Room (in):

32.4Third Leg Room (in):

56.9Third Shoulder Room (in):

43.7Third Hip Room (in):
